Dynabrade 56197 – 6" Hook-Face Disc Pad, Non-Vacuum, Soft Density

Description

Dynabrade 56197 6 Inch Hook-Face Disc Pad, Soft Density

The Dynabrade 56197 is a 6 inch (152 mm) non-vacuum disc pad with a hook-face short nap surface for hook and loop abrasive discs. It is made from soft-density urethane and fits random orbital sanders with a 5/16-24 spindle. The soft density lets the pad flex and conform, which makes it a good choice for smooth finishes on contoured surfaces.

Features and Specifications

• Part number: Dynabrade 56197
• Diameter: 6 inch (152 mm)
• Type: non-vacuum
• Face: hook-face short nap
• Pad material: soft-density urethane
• Thickness: 5/8 inch (16 mm)
• Mount: 5/16-24 male thread
• Design: built to reduce vibration

Fitting the Pad

Thread the pad onto a sander with a 5/16-24 spindle and snug it by hand. Check that it runs true before you start. Use it with 6 inch hook and loop discs. Press each disc on centered and flat so the edge does not overhang, and peel discs off by the edge to avoid pulling the hooks. Always confirm the pad’s speed rating is at or above the sander’s free speed.

Who Uses It

Replacement disc pads are a routine part of keeping random orbital sanders running in auto body shops, cabinet and furniture shops, and metal and composite finishing. A fresh pad restores flat contact with the disc, which gives a more even scratch pattern and better finish.

Care and Replacement

Do not run the sander without a disc on the pad, since the face can be damaged. Keep pressure light so heat does not build up in the urethane. Replace the pad when the hooks wear and discs start to slip or fly off, or when the edge is torn or the face is no longer flat. Store spare pads flat and away from heat.
